Описание на Ресивър за домашно кино NAD T 778
Техническа спецификация на AV Ресивър NAD T 778
Amplifier
- FTC
- 8 Ohms
- 140W (21.5dBW)
- 4 Ohms
- 170W (22.3dBW)
- Full Disclosure Power (all channels driven simultaneously at full bandwidth at rated distortion)
- 9 x 85W
- IHF Dynamic Power
- 8 Ohms
- 165W (22.2dBW)
- 4 Ohms
- 280W (24.5dBW)
- Total harmonic distortion at rated power
- <0.08%
- IM distortion at 1/3 rated power
- <0.03%
- Damping factor
- >300 (20Hz-1kHz, 8 ohms)
- Input sensitivity and impedance
- 1.12Vrms (ref. 8 Ohms, VOL at 0dB)
- Frequency response
- +0.3/-0.8dB (ref. 1kHz, 20Hz-20kHz)
- Signal/noise ratio
- >100dB (ref. rated power at 8 Ohms, A-Weighted)
- Signal/noise ratio
- >85dB (ref. 1W at 8 Ohms, A-Weighted)
Preamplifier
- LINE INPUT
- Frequency response
- ±0.3dB (ref. 20Hz – 20kHz)
- Signal-to-noise ratio
- >100dB (ref. 2V, A-Weighted)
- Total harmonic distortion
- <0.01%
- Input sensitivity
- 245mVrms (ref. 2V)
- Maximum output level
- >4.5Vrms
- PHONO INPUT
- Input Sensitivity
- 6.2mVrms (ref. 2V)(ref. 20Hz – 20kHz)
- Signal-to-noise ratio
- >80dB (ref. 2V, A-Weighted)
- Maximum Input Level
- >90mVrms (1kHz)
Power Consumption
- Standby power
- <0.5W (full standby)
- <8W (network standby)
Dimension and Weight
- Unit Dimensions (W x H x D)
- 435 x 140 x 430mm (Gross)*
- 17 3/16 x 5 9/16 x 16 15/16″**
- Net Weight
- 12.1kg (26.7lb)
- Shipping Weight
- 15.5kg (34.2lb)
